Single-Phase Pole-Mounted Transformer from Subian Electric’s Xuzhou Factory
This one-phase mounted transformer makes it possible to distribute electric power efficiently as well as transforming high-voltage electricity to low voltages used in the households and small business. It complies with DOE 2016 requirements and NEMA TP1 standards in terms of its efficiency level from different perspectives associated with energy losses and its operational costs.
Applications & circuit protection
Single-phase pole transformers are used for providing electricity to rural distribution, residential and light industrial purposes.
- Rural: Village and farm supplying electricity.
- Residential: Household and community supply.
- Light industrial: Small shops and enterprises.
- Utility distribution: Single-phase delivery.
Construction & operating reliability
The slim, thick appearance is perfectly suited for outdoor environments; the effective cores and windings ensure high efficiency levels under no-load and full-load conditions.
- Slim, thick outdoor design.
- A core designed with high efficiency (USA, DOE (2016), NEMA TP1).
- Numerous combinations of primary and secondary voltage.
- Oil-immersed cooling for reliability.
- Temperature rise of 65°C/55°C according to the relevant standards.
Technical Parameter
| Parameter | Value |
| Rated capacity range | 30-2500 kVA |
| Voltage combination (HV) | 6 / 6.3 / 10 / 10.5 / 11 kV |
| Tap range | ±5% / ±2×2.5% |
| Voltage (LV) | 0.4 / 0.69 kV |
| Connection group | Yyn0 / Dyn11 / Yzn11 |
| No-load loss (typical range) | 100-2400 W |
| Load loss (typical range) | 630-24000 W |
| No-load current (typical range) | 0.5-2.3% |
| Short-circuit impedance | 4% |
| Type | Single-phase, oil-immersed, pole-mounted |
| Capacity | 10 – 333 kVA |
| Primary voltage | 4160 – 34600 V options |
| Secondary voltage | 120/240 / 240/480 / 277/346 V options |
| Efficiency | Up to 99.43% (DOE 2016) |
| Temperature rise | 65°C / 55°C |
| Insulation level | <150 kV BIL |
| Standard | DOE 2016 / NEMA TP1 / IEC 60076 |
